🚀 Nected OnPremise Installation (via Helm Charts)

This guide walks you through deploying Nected on your own Kubernetes cluster using Helm charts.

✅ Pre-Requisites

Domain Setup & Ingress Configuration

You’ll need three fully qualified domain names (FQDNs) pointing to your cluster’s ingress controller:

Service Values Placeholder Example Domain
nected-konark <<ui-domain>> app.xyz.com
nected-nalanda <<backend-domain>> api.xyz.com
nected-vidhaan-router <<router-domain>> router.xyz.com

Required Services

Service Requirement
PostgreSQL Database with create/read/write.
Redis Endpoint and authentication details
Elasticsearch Endpoint and authentication details

📌 PostgreSQL Notes

Azure PostgreSQL Flexible Server

  1. Go to the Azure Portal, Navigate to your PostgreSQL Flexible Server instance.
  2. Open “Server Parameters”, In the left-side menu under Settings, click “Server Parameters”.
  3. Find the azure.extensions parameter, Search for azure.extensions using the search bar.
  4. Add btree_gin to the list, If btree_gin is not already listed, append it to the existing list. Example: hstore,pg_trgm,btree_gin
  5. Click Save, This change will not restart the server—it takes effect immediately. Create the Extension in Your Database.
  6. After enabling it in parameters:
    CREATE EXTENSION IF NOT EXISTS btree_gin;

📌 ElasticSearch Notes

Ensure the configured user or API key has the following cluster and index-level privileges:

{
    "read-write-role": {
        "cluster": [
            "monitor",
            "manage_ingest_pipelines",
            "manage_transform",
            "manage_ilm",
            "manage_index_templates"
        ],
        "indices": [{
            "names": ["*"],
            "privileges": [
                "read",
                "write",
                "create_index",
                "manage",
                "view_index_metadata",
                "manage_ilm",
                "monitor"
            ]
        }]
    }
}

💡 For Dev Environments shortcut: Use Nected’s datastore chart if you don’t have PostgreSQL, Redis, or Elasticsearch installed:

🌐 Ingress Setup

📌 Update DNS

Point each domain to your ingress controller’s external IP:

🛠️ Installation Steps

📦 Add Helm Repo

helm repo add nected https://nected.github.io/helm-charts

📄 Download Sample Values Files

🌐 Configure Scheme and Domains

In nected-values.yaml, replace the following placeholders:

Values Placeholder Replace With
<<scheme>> http or https
<<ui-domain>> app.xyz.com
<<backend-domain>> api.xyz.com
<<router-domain>> router.xyz.com

🔐 Configure default user credentials

In nected-values.yaml:

NECTED_UI_USER_NAME: &uiUserName dev@nected.ai
NECTED_UI_USER_PASSWORD: &uiUserPassword devPass123

🗄️ Configure PostgreSQL

  1. In temporal-values.yaml:
    NECTED_PG_HOST: &pgHost datastore-postgresql
NECTED_PG_USER: &pgUser nected
NECTED_PG_PASSWORD: &pgPassword psqlPass123
NECTED_PG_PORT: &pgPort 5432
NECTED_PG_TLS_ENABLED: &pgTlsEnabled false
NECTED_PG_HOST_VERIFICATIO: &pgHostVerification false
  2. In nected-values.yaml:
    NECTED_PG_HOST: &pgHost datastore-postgresql
NECTED_PG_DATABASE: &pgDatabase nected
NECTED_PG_USER: &pgUser nected
NECTED_PG_PASSWORD: &pgPassword psqlPass123
NECTED_PG_PORT: &pgPort "5432"
NECTED_PG_SSL_MODE: &pgSslMode disable

🧠 Configure Redis

In nected-values.yaml:

NECTED_REDIS_TLS_ENABLED: &redisTlsEnabled "false"
NECTED_REDIS_INSECURE_TLS: &redisInsecureTls "true"
NECTED_REDIS_HOST_PORT: &redisHostPort datastore-redis-master:6379
NECTED_REDIS_HOST: &redisHost datastore-redis-master
NECTED_REDIS_PORT: &redisPort "6379"
NECTED_REDIS_USERNAME: &redisUser ""
NECTED_REDIS_PASSWORD: &redisPassword ""

Notes: No changes required if using the Nected-provided datastore.

🔍 Configure Elasticsearch / OpenSearch

In nected-values.yaml:

NECTED_ELASTIC_ENABLED: &elasticEnabled "true"
# possible values: managed / opensearch
NECTED_ELASTIC_PROVIDER: &elasticProvider managed
NECTED_ELASTIC_HOSTS: &elasticHost http://elasticsearch-master:9200
NECTED_ELASTIC_INSECURE_TLS: &elasticInsecureTls "true"
NECTED_ELASTIC_API_KEY: &elasticAPiKey ""
NECTED_ELASTIC_USER: &elasticUser elastic
NECTED_ELASTIC_PASSWORD: &elasticPassword esPass123

Optional: To disable audit logging:

NECTED_ELASTIC_ENABLED: &elasticEnabled "false"

⚙️ Scaling & Secrets

Autoscaling

Default:

Enable:

autoscaling:
  enabled: true
  minReplicas: 2
  maxReplicas: 4

Secrets

Default

Uses ConfigMap:

kubectl create secret generic nected-credential \
  --from-literal=MASTER_DB_PASSWORD=psqlPass123 \
  --from-literal=ELASTIC_PASSWORD=esPass123 \
  --from-literal=DB_PASSWORD=psqlPass123 \
  --from-literal=REDIS_PASSWORD=redisPass123 \
  --from-literal=ELASTIC_API_KEY=your-api-key

Update nected-values.yaml:

existingSecret: nected-credential

🚀 Install Nected Services

  1. Install Temporal:
     helm upgrade -i temporal nected/temporal -f values/temporal-values.yaml
  2. Install Nected:
     helm upgrade -i nected nected/nected -f values/nected-values.yaml

    ✅ Access the Application

    Visit the application via your configured <<ui-domain>>. Login using default credentials defined in nected-values.yaml:

    NECTED_USER_EMAIL: dev@nected.ai
NECTED_USER_PASSWORD: devPass123

Important: username is always an email and password should be alphanumeric at least 8 characters
